JULES
CHECK OUT THE PROJECT PAGE
The core Jules feature is simplicity, going back to the essential elements of bespoke keyboards. A clean, beautifully functional design that makes the best with the least. An outstanding match for your desk space.
Case design by Zambumon. PCB design by wilba.tech
Manufactured and distributed by RAMA WORKS® FOUNDRY
STREAMLINED AND SEAMLESS.
Expertly milled down from a solid piece of aluminium to its final shape and bead-blasted to a high grit finish, Jules offers an elegant and streamlined aesthetic, with a breathtaking side profile that does not go unnoticed.
TOP-MOUNTED. AS IT SHOULD BE.
The Jules plate is attached to the top frame by eight mounting points that have been carefully placed to provide an optimal sound signature and feel. This simple and effective solution has been a mainstay of the custom keyboard scene as it provides a great typing experience.
FOUR EDITIONS TO RULE THEM ALL.
KURO - NAVY - HALT - OURO
MAKE IT YOUR OWN.
Personalize your Jules by pairing it with your favorite MX switches and custom keycap set.
SOLDERLESS OR SOLDERABLE, THE CHOICE IS YOURS.
The wilba.tech WT65-F and WT65-FX PCBs are designed specifically for Jules. A separate extension PCB provides USB-C connectivity that is low and centered at the rear of the keyboard.
The WT65-F uses Kailh hot-swap sockets for assembly without soldering and it’s securely anchored to the plate using standoffs.
The WT65-FX variant is a solderable version without hot-swap sockets for those who prefer a different layout.
The Fixed layout plate is paired with the WT65-F Hotswap PCB. The Variable layout plate is paired with the WT65-FX Solderable PCB.
FIXED LAYOUT
VARIABLE LAYOUT
PROGRAMMING YOUR BOARD HAS NEVER BEEN EASIER.
The WT65-F and WT65-FX are QMK compatible and easily programmable in real-time with VIA.
RAMA × Zambumon
To celebrate the launch of Jules, A limited-edition Cherry Profile Row 1 keycap. MX stem and made from aluminium.
WHAT’S IN THE BOX
1 × Top Enclosure (Aluminium)
1 × Base Enclosure (Aluminium)
1 × Plate (PVD Coated Brass)
1 × wilba.tech WT65-F or WT65-FX PCB
1 × wilba.tech WT-USB-C extension PCB
8 × RW Black M2×6 T10 Fixtures (case)
10 × RW Black M2×4 T10 Fixtures (8x plate, 4x daughterboard)
6 × RW Black M2×3 T10 Fixtures (hotswap PCB only)
6 × RW Black M2×3 CSK T6 Fixtures (hotswap PCB only)
6 × RW Black M2×3.5 Spacers (hotswap PCB only)
1 × RW 65-A Feet
1 × XO Switchpuller
1 × RW T10 Torx Tool
1 × RW T6 Torx Tool
1 × RW Black Metal End USB-C to USB-A braided cable (USB 3.0) - 1.5m
1 × Various Packaging
TECHNICAL SPECS
WEIGHT AND DIMENSIONS
Weight: 1.56 kg (3.44 pound)
Front height: 1.92 cm (0.75 inch)
Width: 32.08 cm (12.63 inch)
Depth: 11.89 cm (4.68 inch)
GENERAL
7.0° slope
Two-piece bead-blasted anodized aluminium enclosure
Top-mounted PVD coated brass plate
USB-C interface
WT65-F or WT65-FX Jules designed by wilba.tech. QMK compatible PCB and fully programmable with VIA configurator
